Dec 23, 2020
Dec 23, 2020

🎄 Twelve Days of SMT 🎄 - Day 12: Community Transformations

Apache Kafka ships with many Single Message Transformations (SMT) included - but the great thing about it being an open API is that people can, and do, write their own transformations. Many of these are shared with the wider community, and in this final installment of the series I’m going to look at some of the transformations written by Jeremy Custenborder and available in kafka-connect-transform-common which can be downloaded and installed from Confluent Hub (or built from source, if you like that kind of thing).
Dec 22, 2020
Dec 22, 2020

🎄 Twelve Days of SMT 🎄 - Day 11: Predicate and Filter

Apache Kafka 2.6 included KIP-585 which adds support for defining predicates against which transforms are conditionally executed, as well as a Filter Single Message Transform to drop messages - which in combination means that you can conditionally drop messages.

As part of Apache Kafka, Kafka Connect ships with pre-built Single Message Transforms and Predicates, but you can also write you own. The API for each is documented: Transformation / Predicate. The predicates that ship with Apache Kafka are:

  • RecordIsTombstone - The value part of the message is null (denoting a tombstone message)

  • HasHeaderKey- Matches if a header exists with the name given

  • TopicNameMatches - Matches based on topic

Dec 21, 2020
Dec 21, 2020

🎄 Twelve Days of SMT 🎄 - Day 10: ReplaceField

The ReplaceField Single Message Transform has three modes of operation on fields of data passing through Kafka Connect:

  • Include only the fields specified in the list (include)

  • Include all fields except the ones specified (exclude)

  • Rename field(s) (renames)

Dec 20, 2020
Dec 20, 2020

Scheduling Hugo Builds on GitHub pages with GitHub Actions

Over the years I’ve used various blogging platforms; after a brief dalliance with Blogger I started for real with the near-inevitable Wordpress.com. From there I decided it would be fun to self-host using Ghost, and then almost exactly two years ago to the day decided it definitely was not fun to spend time patching and upgrading my blog platform instead of writing blog articles, so headed over to my current platform of choice: Hugo hosted on GitHub pages. This has worked extremely well for me during that time, doing everything I want from it until recently.

Dec 17, 2020
Dec 17, 2020

🎄 Twelve Days of SMT 🎄 - Day 8: TimestampConverter

The TimestampConverter Single Message Transform lets you work with timestamp fields in Kafka messages. You can convert a string into a native Timestamp type (or Date or Time), as well as Unix epoch - and the same in reverse too.

This is really useful to make sure that data ingested into Kafka is correctly stored as a Timestamp (if it is one), and also enables you to write a Timestamp out to a sink connector in a string format that you choose.

Dec 16, 2020
Dec 16, 2020

🎄 Twelve Days of SMT 🎄 - Day 7: TimestampRouter

Just like the RegExRouter, the TimeStampRouter can be used to modify the topic name of messages as they pass through Kafka Connect. Since the topic name is usually the basis for the naming of the object to which messages are written in a sink connector, this is a great way to achieve time-based partitioning of those objects if required. For example, instead of streaming messages from Kafka to an Elasticsearch index called cars, they can be routed to monthly indices e.g. cars_2020-10, cars_2020-11, cars_2020-12, etc.

The TimeStampRouter takes two arguments; the format of the final topic name to generate, and the format of the timestamp to put in the topic name (based on SimpleDateFormat).

"transforms"                                     : "addTimestampToTopic",
"transforms.addTimestampToTopic.type"            : "org.apache.kafka.connect.transforms.TimestampRouter",
"transforms.addTimestampToTopic.topic.format"    : "${topic}_${timestamp}",
"transforms.addTimestampToTopic.timestamp.format": "YYYY-MM-dd"
Dec 15, 2020
Dec 15, 2020

🎄 Twelve Days of SMT 🎄 - Day 6: InsertField II

We kicked off this series by seeing on day 1 how to use InsertField to add in the timestamp to a message passing through the Kafka Connect sink connector. Today we’ll see how to use the same Single Message Transform to add in a static field value, as well as the name of the Kafka topic, partition, and offset from which the message has been read.

"transforms"                                : "insertStaticField1",
"transforms.insertStaticField1.type"        : "org.apache.kafka.connect.transforms.InsertField$Value",
"transforms.insertStaticField1.static.field": "sourceSystem",
"transforms.insertStaticField1.static.value": "NeverGonna"
Dec 14, 2020
Dec 14, 2020

🎄 Twelve Days of SMT 🎄 - Day 5: MaskField

If you want to mask fields of data as you ingest from a source into Kafka, or write to a sink from Kafka with Kafka Connect, the MaskField Single Message Transform is perfect for you. It retains the fields whilst replacing its value.

To use the Single Message Transform you specify the field to mask, and its replacement value. To mask the contents of a field called cc_num you would use:

"transforms"                               : "maskCC",
"transforms.maskCC.type"                   : "org.apache.kafka.connect.transforms.MaskField$Value",
"transforms.maskCC.fields"                 : "cc_num",
"transforms.maskCC.replacement"            : "****-****-****-****"
Dec 11, 2020
Dec 11, 2020

🎄 Twelve Days of SMT 🎄 - Day 4: RegExRouter

If you want to change the topic name to which a source connector writes, or object name that’s created on a target by a sink connector, the RegExRouter is exactly what you need.

To use the Single Message Transform you specify the pattern in the topic name to match, and its replacement. To drop a prefix of test- from a topic you would use:

"transforms"                             : "dropTopicPrefix",
"transforms.dropTopicPrefix.type"        : "org.apache.kafka.connect.transforms.RegexRouter",
"transforms.dropTopicPrefix.regex"       : "test-(.*)",
"transforms.dropTopicPrefix.replacement" : "$1"
