The ReplaceField Single Message Transform has three modes of operation on fields of data passing through Kafka Connect:
Include only the fields specified in the list (whitelist)
Include all fields except the ones specified (blacklist)
Rename field(s) (renames)
The Cast Single Message Transform lets you change the data type of fields in a Kafka message, supporting numerics, string, and boolean.
The TimestampConverter Single Message Transform lets you work with timestamp fields in Kafka messages. You can convert a string into a native Timestamp type (or Date or Time), as well as Unix epoch - and the same in reverse too.
This is really useful to make sure that data ingested into Kafka is correctly stored as a Timestamp (if it is one), and also enables you to write a Timestamp out to a sink connector in a string format that you choose.
Just like the RegExRouter, the TimeStampRouter can be used to modify the topic name of messages as they pass through Kafka Connect. Since the topic name is usually the basis for the naming of the object to which messages are written in a sink connector, this is a great way to achieve time-based partitioning of those objects if required. For example, instead of streaming messages from Kafka to an Elasticsearch index called cars, they can be routed to monthly indices e.g. cars_2020-10, cars_2020-11, cars_2020-12, etc.
The TimeStampRouter takes two arguments; the format of the final topic name to generate, and the format of the timestamp to put in the topic name (based on SimpleDateFormat).
"transforms" : "addTimestampToTopic",
"transforms.addTimestampToTopic.type" : "org.apache.kafka.connect.transforms.TimestampRouter",
"transforms.addTimestampToTopic.topic.format" : "${topic}_${timestamp}",
"transforms.addTimestampToTopic.timestamp.format": "YYYY-MM-dd"We kicked off this series by seeing on day 1 how to use InsertField to add in the timestamp to a message passing through the Kafka Connect sink connector. Today we’ll see how to use the same Single Message Transform to add in a static field value, as well as the name of the Kafka topic, partition, and offset from which the message has been read.
"transforms" : "insertStaticField1",
"transforms.insertStaticField1.type" : "org.apache.kafka.connect.transforms.InsertField$Value",
"transforms.insertStaticField1.static.field": "sourceSystem",
"transforms.insertStaticField1.static.value": "NeverGonna"If you want to mask fields of data as you ingest from a source into Kafka, or write to a sink from Kafka with Kafka Connect, the MaskField Single Message Transform is perfect for you. It retains the fields whilst replacing its value.
To use the Single Message Transform you specify the field to mask, and its replacement value. To mask the contents of a field called cc_num you would use:
"transforms" : "maskCC",
"transforms.maskCC.type" : "org.apache.kafka.connect.transforms.MaskField$Value",
"transforms.maskCC.fields" : "cc_num",
"transforms.maskCC.replacement" : "****-****-****-****"If you want to change the topic name to which a source connector writes, or object name that’s created on a target by a sink connector, the RegExRouter is exactly what you need.
To use the Single Message Transform you specify the pattern in the topic name to match, and its replacement. To drop a prefix of test- from a topic you would use:
"transforms" : "dropTopicPrefix",
"transforms.dropTopicPrefix.type" : "org.apache.kafka.connect.transforms.RegexRouter",
"transforms.dropTopicPrefix.regex" : "test-(.*)",
"transforms.dropTopicPrefix.replacement" : "$1"The Flatten Single Message Transform (SMT) is useful when you need to collapse a nested message down to a flat structure.
To use the Single Message Transform you only need to reference it; there’s no additional configuration required:
"transforms" : "flatten",
"transforms.flatten.type" : "org.apache.kafka.connect.transforms.Flatten$Value"Setting the key of a Kafka message is important as it ensures correct logical processing when consumed across multiple partitions, as well as being a requirement when joining to messages in other topics. When using Kafka Connect the connector may already set the key, which is great. If not, you can use these two Single Message Transforms (SMT) to set it as part of the pipeline based on a field in the value part of the message.
To use the ValueToKey Single Message Transform specify the name of the field (id) that you want to copy from the value to the key:
"transforms" : "copyIdToKey",
"transforms.copyIdToKey.type" : "org.apache.kafka.connect.transforms.ValueToKey",
"transforms.copyIdToKey.fields" : "id",You can use the InsertField Single Message Transform (SMT) to add the message timestamp into each message that Kafka Connect sends to a sink.
To use the Single Message Transform specify the name of the field (timestamp.field) that you want to add to hold the message timestamp:
"transforms" : "insertTS",
"transforms.insertTS.type" : "org.apache.kafka.connect.transforms.InsertField$Value",
"transforms.insertTS.timestamp.field": "messageTS"
